Home ProductsHydraulic Oil Pump

Chemicals Viscous Motor Gear Pump Oil YCB25-0.6 YCB25-0.6 Mpa Stainless Steel

Chemicals Viscous Motor Gear Pump Oil YCB25-0.6 YCB25-0.6 Mpa Stainless Steel

  • Chemicals Viscous Motor Gear Pump Oil YCB25-0.6 YCB25-0.6 Mpa Stainless Steel
  • Chemicals Viscous Motor Gear Pump Oil YCB25-0.6 YCB25-0.6 Mpa Stainless Steel
Chemicals Viscous Motor Gear Pump Oil YCB25-0.6 YCB25-0.6 Mpa Stainless Steel
Product Details:
Place of Origin: China
Brand Name: Hydromatic
Certification: ISO9001
Model Number: YCB25-0.6 YCB25-0.6
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: On Request
Packaging Details: Paper
Delivery Time: 7-10 working days
Payment Terms: T/T, Western Union
Supply Ability: 1000/Month
Contact Now
All Products
Industrial Centrifugal Pump (21)
Centrifugal Slurry Pump (9)
Motor Diaphragm Pump (11)
Submersible Sewage Pump (11)
Three Spindle Screw Pump (9)
Magnetic Drive Centrifugal Pump (34)
Stainless Steel Screw Pump (8)
Hydraulic Oil Pump (97)
Multistage Water Pump (17)
Star Type Unloader (7)
Tricone Roller Bits (7)
Explosion Proof Axial Fans (3)
Industrial Valves (14)
Detailed Product Description
Model: YCB25-0.6 YCB25-0.6
High Light:

YCB 25 motor gear pump

,

Chemicals Viscous motor gear pump

,

0.6Mpa oil gear pump

YCB Stainless Steel Gear Pump are used for transfer of Corrosive Chemicals & Viscous Liquids.

Gear pumps manufactures pumps with SS 304/SS 316 construction. The pumps have SS gears and shafts that are nitrided to give longer life with trouble-free performance. The shaft is supported on self lubricating type Teflon coated DU bushes and the sealing is done with PTFE based gland packing which gives zero leakage and is easy to maintain. These pumps are available in flange and foot mounting types. They can operate up to maximum pressure of 16 kg/cm and has suction lift of 5 m at rated speed of 1440 RPM. These pumps are highly suitable for pumping and transfer of corrosive chemicals, acids, dyes, resins, pigment, printing Inks and various other liquids up to viscosity of 1500 cst and temperature of 200C. The pumps are optionally available with built in pressure relief valve. The company also offers simple design cast iron pumps for transfer of non-corrosive liquids, fuel oils, diesel oils, etc, with built-in relief valve facility.SAIKEN pumps for OEMs can also be developed as per requirement.

Brief Intronduction
This series of heat insulating gear pump is used to transfer different medium,such as heavy oil,asphalt,resin.detergent and glue,which not includes solid particles and temperature not higher than 300ºC,with solidifying character under the normal temperature.It also applies to the site with heat instlated requirement in the process technology and outdoors installation at very cold area.
This series of heat insulating gear pump belongs to external gear pump.The tooth form is composite formed by arc and sine Curve.It could transfer many kinds of medium with steady output flow and pressure.There are heat insulating jacket and inlet and outlet joints,on the pump casing,so it could adopt the media,such as heat-conducting oil,steam,hot water and cold water to heat,keep warm and cooling the transferred medium and pump.When the viscosity of transfererred medium is larger than 1500cst,speed should be reduced.

YCB Heat Insulating Gear Pump
Performance Range:
Flow:0.6m⊃3;.h
Different Pressure:0.6Mpa
Rev:910r/min
Working Temperature:max.300ºC
Motor Power:0.75KW
Material:cast iron and stainless steel
Installation:Horizontal installation

YCB  Heat Insulating Gear Pump Specifications:

Model No.
Flow
Speed
Exhaust Pressure
NPSH
Efficiency
Motor
m 3 /h
r/min
Mpa
m
%
Hz
Power KW
Mode No.
YCB0.6-0.6
0.6
910
0.6
5.5
32
50
0.75
Y90S-6
1
1390
0.6
5.5
32
50
0.75
Y80L 2 -4
YCB0.6-2.5
0.6
910
2.5
7
70
50
1.1
Y90L-6
1
1400
2.5
7
70
50
1.5
Y90L-4
YCB1.6-0.6
1.6
910
0.6
5.5
42
50
0.75
Y90S-6
2.5
1400
0.6
5.5
42
50
1.1
Y90S-4
YCB1.6-2.5
1.6
940
2.5
7
71
50
2.2
Y112M-6
2.5
1440
0.6
7
71
50
4
Y112M-4
YCB3.3-0.6
3.3
940
0.6
5
60
50
1.5
Y100L-6
5
1420
0.6
5
60
50
2.2
Y100L 1 -4
YCB3.3-2.5
3.3
960
2.5
7
72
50
5.5
Y132M 2 -6
5
1440
2.5
7
72
50
7.5
Y132M-4
YCB4-0.6
4
960
0.6
5
60
50
1.5
Y100L-6
6
1440
0.6
5
60
50
2.2
Y100L 1 -4
YCB4-2.5
4
960
2.5
7
72
50
5.5
Y132M 2 -6
6
1440
2.5
7
72
50
7.5
Y132M-4
YCB8-0.6
8
960
0.6
5
61
50
3
Y132S-6
12
1440
0.6
5
61
50
5.5
Y132S-4
YCB8-2.5
8
970
2.5
7
75
50
11
Y160L-6
12
1460
2.5
7
75
50
15
Y160L-4
YCB10-0.6
10
960
0.6
5
62
50
4
Y132M 1 -6
15
1140
0.6
5
62
50
5.5
Y132S-4
YCB20-0.6
20
970
0.6
5
68
50
7.5
Y160M-6
24
1170
0.6
5
68
60
11
Y160M-6
YCB25-0.6
25.5
970
0.6
5.5
69
50
11
Y160L-6
30
1170
0.6
5.5
69
60
11
Y160M-6
YCB30-0.6
30
970
0.6
5.5
70
50
11
Y160L-6
36.6
1180
0.6
5.5
70
60
15
Y160L-6
YCB40-0.6
40
970
0.6
5.5
72
50
15
Y180L-6
YCB50-0.6
50
980
0.6
5.5
78
50
22
Y225M-6
60
1190
0.6
5.5
78
60
Y250M-6
YCB80-0.6
80
970
0.6
5.5
65
50
30
Y225M-6
97
1180
50
30
Y225M-6
YCB150-0.6
150
2500
0.6
5.5
65
50
75
Y315S-6
150
2500
0.6
5.5
65
60
75
Y315S-6





Tag:

Chemicals Viscous motor gear pump,

0.6Mpa oil gear pump,

YCB 25 motor gear pump
